R 塑膠葉輪沉⽔泵浦

Product Features-0.5HP-3HP

Except for the impeller, which is made of high-strength engineering plastic, the core parts of this product are all made of SUS304 stainless steel. In addition to excellent quality, it can also ensure excellent water quality and no pollution.
This series is equipped with Franklin motor imported from the United States.

Standard specifications-0.5HP-3HP

Horsepower: 0.5~3hp
Caliber: 1.5"~3"
Standard lift: 16~110m
Standard water volume: 15~150GPM
Applicable well diameter: 4"~5" (R5B/R5D series)
Waterproof grade: IP68

Product Features-5HP-7.5HP

Except for the impeller, which is made of high-strength engineering plastic, the core parts of this product are all made of SUS304 stainless steel. In addition to excellent quality, it can also ensure excellent water quality and no pollution.
This series is equipped with Franklin motor imported from the United States.

Standard specifications-5HP-7.5HP

Horsepower: 5~7.5hp
Caliber: 1.5"~3"
Standard lift: 20~220m
Standard water volume: 15~180GPM
Applicable well diameter: 4"~5" (R5B/R5D series)
Waterproof grade: IP68

Dimensional Performance Sheet

TYPE Model		STAGES	OUTPUT Disc.	MOTOR HP	DIMENSION (mm)						HEAD(M) / CAPACITY(GPM)
					A		B		C	ØΡ	STANDARD		MAX
					1Ø	3Ø	1Ø	3Ø	C	ØΡ	H	C	H	C
4D	R1804	4	1.5"	0.5	505		240		265	95	35	15	49	30
	R1806	6	1.5"	1	611	616	295	300	316	95	48	15	76	30
	R1808	8	1.5"	1.5	737	657	370	290	367	95	70	15	102	30
	R1811	11	1.5"	2	796	786	355	345	441	95	85	15	140	30
	R1815	15	1.5"	3	1008	923	465	380	543	95	110	15	215	30
	R1824	24	1.5"	5	1464	1339	695	570	769	95	180	15	300	30
	R2504	4	1.5"	0.5	510		240		270	95	24	20	43	31
	R2507	7	1.5"	1	645	650	295	300	350	95	38	20	73	31
	R2510	10	1.5"	1.5	805	725	370	290	435	95	59	20	108	31
	R2512	12	1.5"	2	845	835	355	345	490	95	65	20	125	31
	R2517	17	1.5"	3	1130	1045	465	380	665	95	90	20	178	31
	R2526	26	1.5"	5	1616	1491	695	570	921	95	170	20	270	31
	R2536	36	1.5"	7.5		1890		690	1200	95	220	20	375	31

Dimensional Performance Sheet

TYPE Model		STAGES	OUTPUT Disc.	MOTOR HP	DIMENSION (mm)						HEAD(M) / CAPACITY(GPM)
					A		B		C	ØΡ	STANDARD		MAX
					1Ø	3Ø	1Ø	3Ø	C	ØΡ	H	C	H	C
4D	R3505	5	2"	1	640	645	295	300	345	95	24	30	48	47
	R3507	7	2"	1.5	784	704	370	290	414	95	48	30	69	47
	R3509	9	2"	2	841	831	355	345	486	95	55	30	90	47
	R3513	13	2"	3	1097	1012	465	380	632	95	80	30	129	47
	R3518	18	2"	5	1505	1380	695	570	810	95	119	30	179	47
	R3530	30	2"	7.5		1980		690	1290	95	180	30	295	47
	R4005	5	2"	1.5	768	688	370	290	398	95	32	35	49	67
	R4006	6	2"	2	799	789	355	345	444	95	35	35	58	67
	R4008	8	2"	3	1003	918	465	380	538	95	50	35	80	67
	R4013	13	2"	5	1466	1341	695	570	771	95	85	35	135	67
	R4020	20	2"	7.5		1822		690	1132	95	120	35	204	67

Performance/Size Spec Sheet

TYPE Model		STAGES	OUTPUT Disc.	MOTOR HP	DIMENSION (mm)						HEAD(M) / CAPACITY(GPM)
					A		B		C	ØΡ	STANDARD		MAX
					1Ø	3Ø	1Ø	3Ø	C	ØΡ	H	C	H	C
4D	R6005	5	2"	2	775	765	355	345	420	95	23	60	45	97
	R6007	7	2"	3	995	910	465	380	530	95	33	60	64	97
	R6011	11	2"	5	1435	1310	695	570	740	95	60	60	100	97
	R6017	17	2"	7.5		1790		690	1100	95	90	60	158	97
	R8004	4	2"	2	790	780	355	345	435	95	19	80	33	139
	R8005	5	2"	3	965	880	465	380	500	95	23	80	43	139
	R8009	9	2"	5	1473	1348	695	570	778	95	45	80	77	139
	R8013	13	2"	7.5		1780		690	1090	95	65	80	110	139
5D	R5B-3	3	3"	3	940	855	465	380	475	119	16	150	39	220
	R5B-4	4	3"	5	1261	1136	695	570	566	119	26	130	50	220
	R5B-6	6	3"	7.5		1445		690	755	119	40	130	77	220
	R5D-3	3	3"	5	1261	1036	695	570	466	119	20	180	37	290
	R5D-4	4	3"	7.5		1256		690	566	119	30	180	53	290
