6型水式ST白鐵葉輪沉水泵浦
Product Features
- The core parts of this product are all made of SUS304 stainless steel. In addition to excellent quality, it can also ensure high water quality and no pollution.
- This series is equipped with 6-type SUS304 stainless steel three-phase motor; it has strong performance, energy saving and durability.
- Horsepower: 2.0~7.5hp
- Caliber: 1.5"~3"
- Standard lift: 15~240m
- Standard water volume: 15~180GPM
- Applicable well diameter: 6"
- Waterproof grade: IP68
Dimensional Performance Sheet
| TYPE Model | STAGES | OUTPUT | MOTOR HP | DIMENSION (mm) | HEAD(M) / CAPACITY(GPM) | full load current 3/220 | full load current 3/380 | ||||||||
| A | B | C | ØΡ | ØM | STANDARD | MAX | |||||||||
| H | C | H | C | ||||||||||||
| 6D | ST1819 | 19 | 1.5" | 2 | 992 | 330 | 662 | 95 | 140 | 82 | 15 | 140 | 30 | 8 | 4.9 |
| ST1824 | 24 | 1.5" | 3 | 1165 | 330 | 835 | 95 | 140 | 110 | 15 | 180 | 30 | 9 | 6.6 | |
| ST1835 | 35 | 1.5" | 5 | 1661 | 497 | 1164 | 95 | 140 | 180 | 12 | 265 | 30 | 15 | 8.5 | |
| ST1845 | 45 | 1.5" | 7.5 | 2102 | 572 | 1530 | 95 | 140 | 240 | 12 | 355 | 30 | 23 | 13 | |
| ST2514 | 14 | 1.5" | 2 | 857 | 330 | 527 | 95 | 140 | 70 | 20 | 112 | 35 | 8 | 4.9 | |
| ST2519 | 19 | 1.5" | 3 | 993 | 330 | 663 | 95 | 140 | 80 | 20 | 150 | 35 | 9 | 6.6 | |
| ST2530 | 30 | 1.5" | 5 | 1523 | 497 | 1026 | 95 | 140 | 175 | 15 | 240 | 35 | 15 | 8.5 | |
| ST2540 | 40 | 1.5" | 7.5 | 1932 | 572 | 1360 | 95 | 140 | 203 | 15 | 310 | 35 | 23 | 13 | |
性能/尺寸規格表
| TYPE 型式 | STAGES | OUTPUT | MOTOR HP | DIMENSION (mm) | HEAD(M) / CAPACITY(GPM) | full load current 3/220 | full load current 3/380 | ||||||||
| A | B | C | ØΡ | ØM | STANDARD | MAX | |||||||||
| H | C | H | C | ||||||||||||
| 6D | ST3711 | 11 | 2" | 2 | 838 | 330 | 508 | 95 | 140 | 50 | 30 | 92 | 50 | 8 | 4.9 |
| ST3715 | 15 | 2" | 3 | 1002 | 330 | 672 | 95 | 140 | 75 | 30 | 130 | 50 | 9 | 6.6 | |
| ST3725 | 25 | 2" | 5 | 1491 | 497 | 994 | 95 | 140 | 110 | 30 | 210 | 50 | 15 | 8.5 | |
| ST3735 | 35 | 2" | 7.5 | 1927 | 572 | 1355 | 95 | 140 | 165 | 30 | 295 | 50 | 23 | 13 | |
| ST4210 | 10 | 2" | 2 | 805 | 330 | 475 | 95 | 140 | 45 | 35 | 85 | 55 | 8 | 4.9 | |
| ST4213 | 13 | 2" | 3 | 901 | 330 | 571 | 95 | 140 | 56 | 35 | 110 | 55 | 9 | 6.6 | |
| ST4220 | 20 | 2" | 5 | 1330 | 497 | 833 | 95 | 140 | 92 | 35 | 176 | 55 | 15 | 8.5 | |
| ST4230 | 30 | 2" | 7.5 | 1728 | 572 | 1156 | 95 | 140 | 118 | 35 | 260 | 55 | 23 | 13 | |
| ST6506 | 6 | 2"~2.5" | 2 | 827 | 330 | 497 | 95 | 140 | 28 | 50 | 56 | 80 | 8 | 4.9 | |
| ST6508 | 8 | 2"~2.5" | 3 | 941 | 330 | 611 | 95 | 140 | 35 | 50 | 71 | 80 | 9 | 6.6 | |
| ST6512 | 12 | 2"~2.5" | 5 | 1375 | 497 | 878 | 95 | 140 | 65 | 50 | 111 | 80 | 15 | 8.5 | |
| ST6516 | 16 | 2"~2.5" | 7.5 | 1728 | 572 | 1156 | 95 | 140 | 85 | 50 | 147 | 80 | 23 | 13 | |
